Jet Cool Profile Pin
The Jet Cool Profile Pin combines the precise form of a profiled core pin with integrated internal jet cooling. Where a standard round pin cannot form the required geometry, or where a unique cross-sectional profile is required in the die cavity, Vyankatesh Engineering's Profile Pins provide the answer. Each pin is machined to exact profile dimensions, with the internal cooling bore carefully positioned to maximise heat extraction from the thinnest wall sections.
Industries Served
Engineering Detail
Key Features
Custom profile forms machined using CNC milling, wire EDM, and precision grinding
Internal jet cooling bore positioned for maximum thermal benefit
Manufactured from certified DIN 1.2344 H-13 for thermal fatigue resistance
Nitriding provides wear resistance on all profiled surfaces
End-to-end quality management ensures profile accuracy is never compromised
PVD coating applied by trusted partners with thoroughly checked results to increase wear and tear resistance and extend durability
Manufacturing Detail
Material, Finish & Customization
Use Cases
Applications
- Non-circular or profiled hole formations in HPDC dies
- Fins, webs, and boss features with critical cooling requirements
- Complex geometry mold zones requiring both shape accuracy and thermal management
- Intricate automotive casting features where standard round pins are unsuitable
Why Choose Vyankatesh
Key Advantages
Addresses cooling challenge in non-round core features that cannot use standard round pins
Single-component solution combines form and cooling function
Precision wire EDM capability ensures complex profile accuracy
Eliminates the need for secondary cooling circuits around complex features
Quality Standard
Quality Assurance
Profile pins are 100% inspected against customer drawing using precision CMM measurement. Complex profiles are blue-matched to the corresponding die feature before dispatch.
